  • Digital Leakage Current Clamp IBA VIỆT NAM

    • XUẤT XỨ:      GERMANY
      TÌNH TRẠNG:      MỚI 100%
      HÃNG SẢN XUẤT:     IBA AG
  • Thông Tin Sản Phẩm
  • Đánh Giá

Đại lý phân phối chính hãng IBA AG Việt Nam

Digital leakage current clamp 40Hz-1.000Hz, Min/Max, Data Hold. With carrying case, measuring cables, 2 batteries 1,5V , user manual (recommended accessory for BC-700 and BC-600).

Manufacturer: DELTA LOGIC

SKU: 420001XX

Delivery date: 1 week

Product information "Digital Leakage Current Clamp"

Digital leakage current clamp 40Hz-1.000Hz, Min/Max, Data Hold. With carrying case, measuring cables, 2 batteries 1,5V , user manual (recommended accessory for BC-700 and BC-600).



Technical Details



Display: 3-3/4, LCD incl. functions and symbols

Bargraph: 40 segments

Range selection manual

Auto-Power-Off: approx. 30 min.

Overload display: the left digit is blinking

Measuring rate:

20 measurements/sec. (Bargraph)

2 measurements/sec. (LCD)



Clamp opening ca. 30 mm (1.2")

Overvoltage Categorie: CAT II, 600 V, CAT III, 300 V

Battery display: at low battery

Power supply: Battery 2 x 1,5 V IEC LR6 (alkaline)

Current Consumtion: approx. 10 mA

Operation temperature: -10° C … 50° C (14° F... 122° F)

Storage temperature: -20° C … 60° C (-4° F... 140° F)

Humidity: < 75 % relative humidity

Dimension: 183 x 63,6 x 35,6 mm ( 7.2 x 2.5 x 1.4 inch)

Weight: ca. 190 g (7 oz)

Current AC

Range: 0 – 40 mA   Resolution: 10 μA  Accuracy 50/60 Hz: ±(1,5 % rdg. +3 D) Accuracy 40 Hz … 1 kHz: ±(2,0 % rdg. +5 D)

Range: 0 – 400 mA  Resolution: 100 μA Accuracy 50/60 Hz: ±(1,5 % rdg. +3 D) Accuracy 40 Hz … 1 kHz: ±(2,0 % rdg. +5 D)

Range: 0 – 4 A     Resolution: 1 mA   Accuracy 50/60 Hz: ±(1,5 % rdg. +3 D) Accuracy 40 Hz … 1 kHz: ±(2,0 % rdg. +5 D)

Range: 0 – 40 A    Resolution: 10 mA  Accuracy 50/60 Hz: ±(1,5 % rdg. +3 D) Accuracy 40 Hz … 1 kHz: ±(2,0 % rdg. +5 D)

Range: 0 – 50 A    Resolution: 0,1 A  Accuracy 50/60 Hz: ±(1,5 % rdg. +5 D) Accuracy 40 Hz … 1 kHz: ±(2,0 % rdg. +5 D)

Range: 50 – 60 A   Resolution: 0,1 A  Accuracy 50/60 Hz: ±(3,0 % rdg. +5 D) Accuracy 40 Hz … 1 kHz: ±(3,5 % rdg. +5 D)

Voltage AC

Range: 0 – 400 V

Resolution: 0,1 V

Accuracy: 50/60 Hz:  ±(1,0 % rdg. +3 D)

40 Hz … 1 kHz: ±(2,0 % rdg. ± 4 D)

Resistance

Range: 400 Ω

Resolution: 0,1 Ω

Accuracy: ±(1 % rdg. +3 D)

Overload Protection: 600 V AC

Continuity



Range: Ω/*T

Resolution: 0,1 Ω

Beep: < ca.40 Ω

Open Circuit Voltage: < 0,4 V

Overload Protection: 600 V
